MCW025-040E | Walkie counterbalanced stacker
Counterbalanced pallet stackers

Walk-behind counterbalanced solution for pallet stacking and retrieval

Walkie counterbalanced stacker

Models
MCW025-040E
Capacity
2500-4000lbs

The MCW-E series comes in 2,500, 3,000 and 4,000-pound capacities, with ergonomics and maneuverability to optimize precision and operator productivity in the most demanding operations.

  • Operator-friendly features
  • Built for productivity
  • Easy service
Industry Sectors

- Food Distribution and Processing
- Warehouse & 3PL
- Wholesale Distribution
- Home Centers
- Retail & E-Commerce (DC/fulfillment)
- Retail Store Operations
- Furniture & Furnishings
- Auto Parts Distribution
- Health & Pharma
- Chemicals & Plastics

Start a quote

Interested in more information on this lift truck? Our solutions team is available to discuss your specific application and how this product can meet your needs.

Start a quote

High-Performance Solution for Pallet Transport and Stacking

Walkie stacker built for lasting productivity

Operator-friendly features

Best-in-class ergonomic features come together to keep operators fresh, helping boost productivity in even the most demanding, long shifts.

  • Bottom-mounted tiller handle design optimizes the operating position and reduces steering effort
  • Consolidated control layout, with lift/lower, tilt and more all located on tiller handle
  • Rotary throttle control designed for maximum tactile feel and reduced operator fatigue
Built for productivity

Smartly designed features help operators harness the true potential of the walkie counterbalanaced stacker from Yale.

  • Three performance modes allow operators to tailor truck performance to the application
  • Auto Deceleration System reduces the need to manually apply service brake to slow truck
  • Creep speed control (optional) helps improve maneuverability in tight spaces
  • Hi-Vis mast offers solid construction and excellent visibility to help boost operator performance
  • Convenient tilting mast with flexibility of five degrees back and four degrees forward
Easy service

The walkie counterbalanced is designed for easy service access and maintenance.

  • One power contactor reduces components that require maintenance in the first place
  • Durable compartment cover requires no tools to remove for easy service access
  • Drive unit with integrated steer bearing and string guard for lower maintenance requirements and lasting durability
  • Translucent hydraulic tank for quick inspection of oil level
  • Multi-function display (optional) provides battery state of charge, truck hours, fault codes and lift interrupt warning
  • Low battery lift interrupt to help avoid failure
Model Load Capacity Lift Height Battery Capacity Voltage Weight
MCW025E 2500lbs 126 24V / 375-510Ah 4194
MCW030E 3000lbs 126 24V / 375-510Ah 4917
MCW040E 4000lbs 122 24V / 375-510Ah 5496
